Cisco WAP321 Administration Guide

Getting Started
Getting Started
Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 12
1
Getting Started
To simplify device configuration through quick navigation, the Getting Started
page provides links for performing common tasks. The Getting Started page is the
default window every time you log into the configuration utility.
Links on the Getting Started Page
Category Link Name (on the Page) Linked Page
Initial Setup Run Setup Wizard Using the Access
Point Setup Wizard
Configure Radio Settings Radio
Configure Wireless Network Settings Networks
Configure LAN Settings LAN
Run WPS WPS Setup
Configure Single Point Setup Single Point Setup
Device
Status
System Summary System Summary
Wireless Status Network Interfaces
Quick
Access
Change Account Password User Accounts
Upgrade Device Firmware Upgrade Firmware
Backup/Restore Configuration Download/Backup
Configuration File
Other
Resources
Support A link to the Cisco WAP
support site.
Forums A link to the Cisco
Support Community
site.
Wireless Planning Tool A link to Fluke networks
AirMagnet Planner for
Cisco Small Business.

Cisco WAP321 Specifications

General

Modulation	OFDM
Frequency band	2.4 - 5 GHz
Number of users	32 user(s)
Channels quantity	13 channels
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Certification	FCC class B, CE, IC, Wi-Fi
LED indicators	Power, WAN, WLAN
Supported network protocols	IEEE802.11b/g/n/i/e, 802.3, 802.3u, 802.1X, IPv4, IPv6, HTTP/HTTPS, SNMP
WAN connection	Wi-Fi
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA2, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	275 g
Dimensions (WxDxH)	169.08 x 169.42 x 35 mm
