Simple Network Management Protocol
Ta r g e t s
Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 141
8
• Group—The group that the user is mapped to. The default groups are
RWAuth, RWPriv, and RO. You can define additional groups on the SNMP
Groups page.
• Authentication Type—The type of authentication to use on SNMPv3
requests from the user, which can be one of these options:
- MD5—Require MD5 authentication on SNMP requests from the user.
- None—SNMPv3 requests from this user require no authentication.
• Authentication Pass Phrase—(If you specify MD5 as the Authentication
Type) A pass phrase to enable the SNMP agent to authenticate requests
sent by the user. The pass phrase must be between 8 and 32 characters in
length.
• Encryption Type—The type of privacy to use on SNMP requests from the
user, which can be one of these options:
- DES—Use DES encryption on SNMPv3 requests from the user.
- None—SNMPv3 requests from this user require no privacy.
• Encryption Pass Phrase—(If you specify DES as the privacy type) A pass
phrase to use to encrypt the SNMP requests. The pass phrase must be
between 8 and 32 characters in length.
STEP 5 Click Save. The user is added to the SNMPv3 Users list and your changes are
saved to the Startup Configuration.
NOTE To remove a user, select the user in the list and click Delete.
Targets
SNMPv3 targets send SNMP notifications using Inform messages to the SNMP
Manager. For SNMPv3 targets, only Informs are sent, not traps. For SNMP versions
1 and 2, traps are sent. Each target is defined with a target IP address, UDP port,
and SNMPv3 user name.
NOTE SNMPv3 user configuration (see the Users page) should be completed before
configuring SNMPv3 targets.
NOTE The WAP device supports a maximum of eight targets.
