Cisco WAP321 Administration Guide

Simple Network Management Protocol
Ta r g e t s
Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 142
8
To a d d S N M P t a r g e t s :
STEP 1 Select SNMP > Targets in the navigation pane.
STEP 2 Click Add. A new row is created in the table.
STEP 3 Check the box in the new row and click Edit.
STEP 4 Configure the parameters:
• IP Address—Enter the IPv4 address of the remote SNMP manager to
receive the target.
• UDP Port—Enter the UDP port to use for sending SNMPv3 targets.
• Users—Enter the name of the SNMP user to associate with the target. To
configure SNMP users, see the Users page.
STEP 5 Click Save. The user is added to the SNMPv3 Targets list and your changes are
saved to the Startup Configuration.
NOTE To remove an SMMP target, select the user in the list and click Delete.

Cisco WAP321 Specifications

General

Modulation	OFDM
Frequency band	2.4 - 5 GHz
Number of users	32 user(s)
Channels quantity	13 channels
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Certification	FCC class B, CE, IC, Wi-Fi
LED indicators	Power, WAN, WLAN
Supported network protocols	IEEE802.11b/g/n/i/e, 802.3, 802.3u, 802.1X, IPv4, IPv6, HTTP/HTTPS, SNMP
WAN connection	Wi-Fi
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA2, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	275 g
Dimensions (WxDxH)	169.08 x 169.42 x 35 mm
