Administration
Upgrade Firmware
Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 41
3
!
CAUTION Verify any IP address that you enter. If you enter an IP address that does not match
your Administrative computer, you will lose access to the configuration interface. It
is highly recommend to give the Administrative computer a static IP address, so the
address does not change over time.
To create an access list:
STEP 1 Select Administration > Management Access Control in the navigation pane.
STEP 2 Select Enable for the Management ACL Mode.
STEP 3 Enter up to five IPv4 and five IPv6 addresses that will be allowed access.
STEP 4 Verify the IP addresses are correct.
STEP 5 Click Save. The changes are saved to the Startup Configuration.
Upgrade Firmware
As new versions of the WAP device firmware become available, you can upgrade
the firmware on your devices to take advantage of new features and
enhancements. The WAP device uses a TFTP or HTTP client for firmware
upgrades.
After you upload new firmware and the system reboots, the newly added
firmware becomes the primary image. If the upgrade fails, the original firmware
remains as the primary image.
NOTE When you upgrade the firmware, the access point retains the existing configuration
information.
TFTP Upgrade
To upgrade the firmware on an access point using TFTP:
