Cisco WAP321 Administration Guide

Getting Started
Window Navigation
Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 14
1
Management Buttons
The table below describes the commonly used buttons that appear on various
pages in the system.
Management Buttons
Button Name Description
Add Adds a new entry to the table or database.
Cancel Cancels the changes made to the page.
Clear All Clears all entries in the log table.
Delete Deletes an entry in a table. Select an entry first.
Edit Edits or modifies an existing entry. Select an entry first.
Refresh Redisplays the current page with the latest data.
Save Saves the settings or configuration.
Update Updates the new information to the startup
configuration.

Cisco WAP321 Specifications

General

Modulation	OFDM
Frequency band	2.4 - 5 GHz
Number of users	32 user(s)
Channels quantity	13 channels
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Certification	FCC class B, CE, IC, Wi-Fi
LED indicators	Power, WAN, WLAN
Supported network protocols	IEEE802.11b/g/n/i/e, 802.3, 802.3u, 802.1X, IPv4, IPv6, HTTP/HTTPS, SNMP
WAN connection	Wi-Fi
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA2, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	275 g
Dimensions (WxDxH)	169.08 x 169.42 x 35 mm
