Cisco WAP321 Administration Guide

LAN
IPv6 Addresses
Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 60
4
To configure IPv6 address settings:
STEP 1 Select LAN > IPv6 Addresses in the navigation area.
STEP 2 Configure the following settings:
• IPv6 Connection Type—Choose how the WAP device obtains an IPv6
address:
- DHCPv6—The IPv6 address is assigned by a DHCPv6 server.
- Static IPv6—You manually configure the IPv6 address. The IPv6 address
should be in a form similar to xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx:xxxx
(2001:DB8::CAD5:7D91).
• IPv6 Administration Mode—Enables IPv6 management access.
• IPv6 Auto Configuration Administration Mode—Enables IPv6 automatic
address configuration on the WAP device.
When enabled, the WAP device learns its IPv6 addresses and gateway by
processing the Router Advertisements received on the LAN port. The WAP
device can have multiple autoconfigured IPv6 addresses.
• Static IPv6 Address—The static IPv6 address. The WAP device can have a
static IPv6 address even if addresses have already been configured
automatically.
• Static IPv6 Address Prefix Length—The prefix length of the static address,
which is an integer in the range of 0 to 128. The default is 0.
• Static IPv6 Address Status—One of the following values appears:
- Operational—The IP address has been verified as unique on the LAN
and is usable on the interface.
- Tentative—The WAP device initiates a duplicate address detection
(DAD) process automatically when a static IP address is assigned. An
IPv6 address is in the tentative state while it is being verified as unique on
the network. While in this state, the IPv6 address cannot be used to
transmit or receive ordinary traffic.
- Blank (no value)—No IP address is assigned or the assigned address is
not operational.
• IPv6 Autoconfigured Global Addresses—If the WAP device has been
assigned one or more IPv6 addresses automatically, the addresses are
listed.

Cisco WAP321 Specifications

General

Modulation	OFDM
Frequency band	2.4 - 5 GHz
Number of users	32 user(s)
Channels quantity	13 channels
Networking standards	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Certification	FCC class B, CE, IC, Wi-Fi
LED indicators	Power, WAN, WLAN
Supported network protocols	IEEE802.11b/g/n/i/e, 802.3, 802.3u, 802.1X, IPv4, IPv6, HTTP/HTTPS, SNMP
WAN connection	Wi-Fi
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA2, WPS
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	275 g
Dimensions (WxDxH)	169.08 x 169.42 x 35 mm
