10 LMC-64 metering card
The Level Meter Card (LMC-64) interface card enables the Eclipse HX-
Median to provide audio level metering for Production Maestro Pro over a
network.
Each LMC-64 interface card can meter up to 64 virtual partylines (conferences)
and four-wire ports.
The LMC-64 interface comprises:
A front card with a reset button and various status indicators (including
status LEDs for power, port activity and LAN status).
Note: The port activity LEDs are inactive on the LMC-64 front card as
the E1/T1 ports are not used.
A rear card with eleven RJ45 ports giving eight E1/T1 ports (not used),
DECT sync in and out (not used) and a LAN port used for the IP
connection.
Note: An Ethernet cable must be connected to the LMC-64 interface LAN port for the
card to function correctly.
Note: For an overview of the Eclipse HX-Median, see 3 Overview.
