User Guide| Eclipse HX-Median
Frame Data Light
The green frame data light flashes (1: 1 0.5Hz) to indicate
successful communication between the port card and the CPU
card.
Status Light
The red status light illuminates to indicate a failure in
communication between the port card and the CPU card.
Table 12: Key to MVX-A16 analog front panel lights and controls
5.7 Diagnosing power supply problems
The Eclipse HX-Median has two Euro Cassette power supply units. One power
supply unit can power an entire matrix. The second unit provides a backup in
case of an equipment failure.
Eclipse HX-Median matrices may be fitted with XP (part 740101Z) or Power-
One (part 720379Z) power supply units, depending on the date of manufacture.
Each cassette has two status lights located on the power supply unit in the upper
left corner.
The green light stays on continuously to indicate that the unit is receiving
appropriate power. The amber (XP unit) or red (Power-One) light goes on when
a DC output or AC input falls too low.
The different types of power supply units must not be mixed in
an Eclipse HX-Omega matrix; if one of the pair of power supplies
is replaced it must be replaced with the same type of power
supply unit. If this is not possible both power supplies must be
replaced with power supply units of the same type.
Power-One power supplies are identified by the part number on
the front of the unit; XP units do not have a part number on the
front of the unit.
