User Guide | Eclipse HX-Median
Any of the Eclipse HX matrix’s analog input/output RJ-
45 connectors that are used to connect cable from the
matrix to panels and interfaces.
Each port connects to a separate audio channel in the
matrix.
A label that is temporarily assigned and replaces a
previously labeled port or conference.
A bus is the channel or path between the components
in the matrix along which electrical signals flow to
carry information from one component to the next. In
the Eclipse HX matrix the bus is located in the etched
surface of the midplane.
A call signal is an electronic signal sent from one panel
or interface to another. A call signal can be audible
and/or visual. Typically a call signal is sent to get the
attention of a panel operator who may have turned
down their intercom speaker’s volume or removed
their headset. It can also be sent to activate an
electronic relay.
The assignment area of the Production Maestro
software which can have any user labeled background.
EIA/TIA 568 category specification relating to network
cabling. Shielded category-5 cabling is required for
Eclipse HX matrix wiring.
Digital wireless communications product. Sold under
the CellCom name in USA and as FreeSpeak in Europe
and Asia.
The term central matrix is used to differentiate the
central hardware and software of the intercom system
from the connected audio devices. The central matrix
consists of:
The metal housing for the circuit cards and power
supplies.
The circuit cards.
The power supplies.
The rear panel connectors which connect the matrix’s
hardware to panels and interfaces.
