User Guide | Eclipse HX-Median
Page 147
14.8 E-MADI64 fiber transceiver
Category
Measures / comments
Type
Multimode SFP Transceiver
Wavelength
1310nm
Connector
Duplex LC
Standard Max Node Length
2km (other distances (achieved using
the optional single mode fiber module)
are available to special order.)
Table 32: E-MADI64 fiber transceiver
Note: The standard multimode fiber module is a Class 1 LED Product . The optional single
mode fiber module is a Class 1 Laser Product .
14.9 E-MADI64 clock sources
Clock type
Clock source
Word Clock
44.1KHz
48KHz
96KHz
SD Video
NTSC
PAL
HD Tri-Level Sync
720P60
720P59.94
720P50
720P30
720P27.97
720P25
720P24
720P23.98
1080P60
1080P59.94
1080P50
1080P30
1080P29.97
1080P25
1080P24
1080P23.98
1080I30
1080I29.97
1080I25
1080I24
