8 E-QUE E1/T1 card
The E-QUE interface card allows you to connect the Eclipse matrix to
FreeSpeak/CellCom/ FreeSpeak II antennas and FreeSpeak/CellCom/FreeSpeak
II antenna splitters, E1 and T1 trunk lines and E1 direct lines.
The E-QUE interface cards must be fitted in the rightmost available slots on the
HX-Omega (furthest from the CPU cards). Up to four E-QUE interfaces can be
fitted to an Eclipse HX-Median matrix. The FreeSpeak/CellCom connection
options supported are:
Up to 8 x FreeSpeak/CellCom/FreeSpeak II antenna direct connections
per E-QUE interface.
Up to 2 x FreeSpeak/CellCom/FreeSpeak II splitter connections (up to 5
antennas each) per E-QUE interface.
Using all four E-QUE interfaces that can be fitted would allow up to 40 antennas
and 200 beltpacks to be connected to a matrix. The E-QUE interface also
provides facilities for Direct and Trunk connections using E1 protocol and Trunk
connections over T1 protocol. There are:
30 audio channels on each of 2 connectors (60 channels in total)
available in E1 mode.
24 audio channels on each of 2 connectors (48 channels per card in
total) are available in T1 mode.
Each E-QUE interface consists of a front card with a reset button and various
status indicators, and a rear card with eleven RJ45 ports giving eight standard
ports, DECT sync in and out and a LAN port. Each E-QUE front card has status
LEDs for power, port activity and LAN status. The port activity LEDs indicate
whether there is a device connected to an E1 port and that a connection has
been established between this port and the connected device.
Note: You do not require an Ethernet cable connected to the E-QUE card LAN port for
the card to function correctly.
For an overview of the Eclipse HX-Median matrix, see 3 Overview.
