3.5 EHX configuration software
The Eclipse HX (EHX) configuration software controls the operation of the
connected audio devices by sending signals to the circuit cards in the matrix,
which then relay the signals to the audio devices.
Configurations (the operating parameters of complete system setups) are
usually created on the EHX computer.
Up to four complete system configurations can be stored in the CPU card of the
Eclipse
HX-Median, for retrieval and activation when required. The external PC that
hosts the EHX software can store an almost unlimited number of complete
system configurations (the number is only limited by the available memory
space on the PC). You can download the configurations to the Eclipse HX-Median
as required.
EHX 8.5.1 runs on the following versions of Windows:
Microsoft Windows 7 (32-bit and 64-bit).
Microsoft Windows 8.1 (32-bit and 64-bit)
Microsoft Windows 10 (32-bit and 64-bit)
Microsoft Windows Server 2008 R2 (64-bit)
Microsoft Windows Server 2012 R2 (64-bit)
Note: Operation on other platforms is no longer supported.
When running EHX on Windows operating systems, the client and server can run
on separate machines connected over a network. You can use EHX to perform a
wide range of configuration tasks, including:
Assigning labels (names) to ports and user panels.
Creating point-to-point and fixed group (partyline) communications
between connected audio devices.
Enabling, limiting or disabling features of any connected user panel or
card.
Configuring connections between matrix frames.
Note: The above list is not definitive. For more information about the capabilities of
EHX, see EHX Help.
The EHX system can be set up to run on a client/server model over a network,
allowing the system administrator to control multiple matrices remotely.
3.6 User panels
The following Clear-Com user panels are compatible with the Eclipse HX-Median:
V-Series panels, including expansion panels.
