User Guide| Eclipse HX-Median
3 Overview
This chapter provides an overview of the Eclipse HX-Median matrix frame,
including the interface cards and interface modules that can be fitted to the
frame.
3.1 Eclipse HX matrix frames
There are four types of Eclipse HX matrix frame available from Clear-Com:
The Eclipse HX-Median has
slots for 2 CPU cards, 7
interface cards, and 8 interface
modules in a six rack unit
(6RU) frame.
For more information, see this
guide.
The largest matrix frame in
the Eclipse HX range.
The Eclipse HX-Omega has
slots for2 CPU cards and 15
interface cards in a six rack
unit (6RU) frame. For more
information, see the Eclipse
HX-Omega User Guide.
The Eclipse HX-Delta has slots
for 2 CPU cards, 4 interface
cards and 3 interface modules
in a three rack unit (3RU)
frame.
For more information, see the
Eclipse HX-Delta User
Guide.
