User Guide| Eclipse HX-Median
Warning: Eye Safety
This LED based single mode transceiver is a Class 1 LED product. It
complies with IEC 60825-1/A2:2001 and FDA performance standards for laser
products (21 CFR 1040.10 and 1040.11) except for deviations pursuant to Laser
Notice 50, dated July 26, 2001.
Normally a protective plug is fitted to the fiber connector to protect the
connector from damage or the entry of foreign materials. The protective plug
should only be removed in order to fit the fiber optic cable. Replace the plug
when the cable is unplugged.
Key to E-MADI64 rear panel connectors
MADI Fiber connector (Tx and Rx)
The connector is a fiber (MM) SFP Duplex LC removable
transceiver module
MADI IN coaxial connector
MADI OUT coaxial connector
Video / Word clock coaxial connector
The clock source is either NTSC/PAL Black and burst, Tri Level HD
video sync or AES Word Clock.
Table 15: Key to E-MADI64 rear panel connectors
6.3 MADI channels
The E-MADI64 card can route up to 64 MADI channels of audio.
Note: The channel modes for the E-MADI64 are 32, 56 and 64. For more information,
see Table 16: E-MADI 64 channel modes.
Each MADI audio channel:
Carries one (or a mixture of) any of the 512 Eclipse HX-Median
backplane timeslots.
Is 24 bits in length.
You can configure the input and output gain for each MADI audio channel in EHX
and / or Production Maestro Pro software. The configurable range for MADI audio
channels is -72dB to +18dB.
