Key to IVC-32 front panel lights and controls
RESET button
Pressing the reset button causes the card and all links to
momentarily stop their current activity and to restart.
During the reset, configuration information downloads to the
card from the CPU card. If the entire system is operating except
for one LMC-64 interface press the reset button for that card
only.
Tip: The reset button is slightly recessed from the front panel to
prevent it from being accidentally pressed. A tool such as a bent
paper clip is required to press this button.
Power supply light
+3.3-Volt Power Supply Light
The matrix’s +3.3-volt power supply provides electric current to
this green light. When lit, the light indicates that the +3.3-volt
supply is present and supplying power to the card.
Status lights (normally inactive)
When lit, a yellow status light indicates successful
communication between an E1/T1 port on the LMC-64 interface
and a connected E1/T1 device such as an active antenna or
splitter.
However, under normal circumstances, E1/T1 devices are not
connected to an LMC-64 interface, which means that these
lights are normally inactive.
LAN DATA
The green LAN DATA light illuminates to indicate there is data
passing through the Ethernet port.
LAN LINK
The amber LAN LINK light illuminates to indicate a connection
to the LAN port.
Table 23: Key to LMC-64 front panel lights and controls
