User Guide| Eclipse HX-Median
Key: Eclipse HX-Median front panel
Interface module slots (unused in this example). The Eclipse
HX-Median can house up to 8 interface modules. Blank panels can
be installed to unused slots. For more information about interface
modules, see 3.4 Interface modules.
CPU cards (P1 and P2). 2 CPU cards are supplied with the
matrix, but only one rear-panel CPU card is required. Whichever of
the two front-installed CPU cards is acting as master will work in
conjunction with this card. For more information, see 3.2.4 CPU
card.
Interface cards. Up to 7 interface cards can be installed to the
matrix. Blank panels can be installed to unused slots. For more
information, see 3.3 Interface cards.
In Figure 2, the cards shown in slots 1 and 2 are MVX-A16 analog
port cards. MVX-A16 cards are used to connect user panels and
interfaces. For more information about MVX-A16 cards, see 3.3.1
MVX-A16 analog port card.
Twin power supplies. The two Euro Cassette power supply units
can be easily installed or removed as required. One power supply
unit can power an entire matrix. The second unit provides a backup
in case of failure or damage to the first unit. For more information,
see 3.2.2 Power supplies.
Table 2: Key to Eclipse HX-Median front panel
