Note: Channel LEDs on the front of the E-MADI card will oscillate
between two channel numbers when the number of channels
received differs from the number of channels set in EHX.
F
Diagnostics
Active LED
The Active (frame data) LED flashes green (1:1 at 0.5Hz) to
indicate successful communication between the E-MADI64 master
card and the CPU card.
Error LED
The Error (status) LED is lit solid red when there is no clock
source or MADI input.
Note: During boot up, the Active and Error LEDS flash rapidly until
the boot sequence is completed.
Table 14: Key to E-MADI64 lights and controls
