Climax KM3000 - Igure A-31. Hydraulic Motor Assembly (P;N 35002)

Page 86 KM3000 KM4000 Operating Manual
FIGURE A-31. HYDRAULIC MOTOR ASSEMBLY (P/N 35002)
PARTS LIST
DESCRIPTIONP/N:QTYITEM
SCREW 1/4-20 X 5/8 SHCS
1241821
SCREW 1/4-28 X .75 SHCS
1264712
FTG ELBOW SAE-6 MALE X #6 JIC MALE 90 DEG
1284923
SCREW 1/4-28 X 5/8 FHSCS
1285334
MOTOR HYD 0.79 CU IN STRAIGHT SAE O-RING
142611
5
GEAR SPUR MOTOR 16DP 1.625PD SPECIAL HYD MOTOR
2037916
FLANGE MOTOR MTG HYD 4TH GEN GEARBOX
350031
7
LABEL WARNING CRUSH FOOT
7874118
LABEL WARNING FLYING DEBRIS/LOUD NOISE
78748 19
LABEL WARNING - CUTTING OF FINGERS OR HAND ROTATING BLADE GRAPHIC 1.13
TALL TRIANGLE YELLOW
79848110
ASSY HOSE 3/8 X 1/2 QD MALE X #6 JICF X 24 CE80041211
4
11
3
10
9
8
5
7
1
6
2
