Climax KM3000 - Ratio Assembly (P;N 103341)

Page 74 KM3000 KM4000 Operating Manual
FIGURE A-19. GEARBOX 3.5 RATIO ASSEMBLY (P/N 103341)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
SCREW 10-32 X 5/8 SHCS1015761
PIN DOWEL 3/8 DIA X 11102722
BRG NEEDLE 3/8 ID X 9/16 OD X .500 OPEN1103723
SCREW 8-32 x 1/2 SHCS11845
74
GEAR SPUR 16DP 56T 20PA .43 X .97LG STEEL155171
5
LABEL WARNING - CUTTING OF FINGERS OR HAND ROTATING BLADE GRAPHIC 1.13 TALL TRIANGLE
YELLOW
7984816
3.5 RATIO GEARBOX COVER
1033431
7
3.5 RATIO GEARBOX HOUSING
10334418
GEAR SPUR 16DP 16T 20PA .38LG STEEL
10334629
WASHER THRUST 3/8 ID X 3/4 OD X 1/16 OILITE
103781410
SEAL .8125 ID X 1.250 OD X .18
103792111
6
4
7
5
1
8
2
3
9
11
10
10
