FIGURE A-5. KM4000 CHART ASSEMBLY (P/N 103884)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
CLAMP ASSY CHAIN KM40001049111
BASE ASSY KM40001326212
SLIDE CROSS ASSY KM4000
1373613
(NOT SHOWN) CRATE 18 X 19 X 13-5/8 KM4000 5/8 PLY HINGED
1536914
(NOT SHOWN) MANUAL INSTRUCTION KM3000 KM4000 KEY MILL
10407516
(NOT SHOWN) WRENCH HEX SET FOLDING 5/64 - 1/4 9 PCS CLIMAX LOGO (KB)
341811
5
ASSY TOPSLIDE WELDON SHANK ELECTRIC INCH/METRIC KM4000 PM4200SEE CHART
1
7
ASSY LEADSCREW CROSS SLIDESEE CHART
18
AVAILABLE CONFIGURATIONS
PART NO. DESCRIPTION ITEM 7 ITEM 8
103907
MODEL KM4000 INCH 120V
103899 16263
103908 MODEL KM4000 METRIC 120V 103900 16264
103909 MODEL KM4000 INCH 230V 103901 16263
103910
MODEL KM4000 METRIC 230V
103902 16264
7
2
1
8
3
