Page 68 KM3000 KM4000 Operating Manual
FIGURE A-13. CLAMP ASSEMBLY (P/N 15647)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
NUT 3/4-10 STDN ZINC PLATED1019721
WASHER THRUST .750 ID X 1.250 OD X .123
1019822
ASSY CLAMP BOLT KM3000
1042223
CASTING BLOCK CLAMP SMALL
1550424
CLAMP BAR
156431
5
SCREW 1/2-13 X 1 LHSCS
1567026
4
6
3
5
2
1
