Page 78 KM3000 KM4000 Operating Manual
FIGURE A-23. ELECTRIC MOTOR ASSEMBLY (P/N 103702)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
BRG BALL .6693 ID X 1.3780 X .391184911
SCREW M5 X .8 X 40mm SHCS 57541
4
2
LABEL WARNING - WEAR EAR PROTECTION5903713
LABEL WARNING - CONSULT OPERATOR'S MANUAL 1.5 DIA590441
4
LABEL WARNING CRUSH FOOT GRAPHIC 1.13 TALL TRIANGLE YELLOW787411
5
LABEL WARNING FLYING DEBRIS/LOUD NOISE7874816
LABEL WARNING - DO NOT EXPOSE TO WATER
788241
7
NFIS ADAPTER METABO ANGLE POLISHER
10368118
KNOB ADJUSTMENT 2 INCH KNURLED LOW PROFILE
10381119
GEAR SPURSEE CHART
110
CHART NFIS MOTOR ELECSEE CHART
111
SCREW 5/8-11 X 1 SSSCN
103886112
AVAILABLE CONFIGURATIONS
PART NO. DESCRIPTION ITEM 11 ITEM 12
103342
MOTOR ASSY ELECTRIC 120v 16T
103347 103499
103703
MOTOR ASSY ELECTRIC 230V 16T
103705 103500
7
6
5
4
3
11
11
11
1
8
2
11
10
9
12
