Climax KM3000 - Igure A-22. Spindle and Quill Assembly Metric (P;N 16022)

P/N 104075, Rev. 0 Page 77
F
IGURE A-22. SPINDLE AND QUILL ASSEMBLY METRIC (P/N 16022)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
BRG BALL .7874 X 1.8504 X .5512 2/SHLDS1015011
ASSY QUILL 2ND KM3000 1.75 TRAVEL1551412
SEAL 1.500 ID X 1.874 OD X .2501566913
ASSY SPINDLE 16MM METRIC 3RD KM30001602314
4
3
2
1
