Climax KM3000 - Igure A-11. Base and Top Slide Assembly (P;N 28839)

Page 66 KM3000 KM4000 Operating Manual
FIGURE A-11. BASE AND TOP SLIDE ASSEMBLY (P/N 28839)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
SCREW 1/4-20 X 5/8 SSSHDPPL1018961
CRANK HANDLE 1/2 SQUARE
1020312
SCREW DRIVE #2 x 1/4 HOLE SIZE .089
1058843
BASE 2ND KM3000
1550514
GIB .4915 X .1562 X 6.76 0-1 6 SS X 1.25
156161
5
CLAMP ASSY STANDARD KM3000
1564716
ASSY TOP SLIDE INCH 2ND KM3000
156561
7
CRATE 9 X 24 X 11-7/8 KM3000 5/8 PLY HINGED (NOT SHOWN)
1601118
PLATE MASS CE
2915219
ASSY LEADSCREW TOP SLIDE KM3000
38091110
6
3
9
7
2
10
1
4
5
