Climax KM3000 - Igure A-26. Pneumatic Conditioning Unit Schematic and Parts List (P;N 101920)

P/N 104075, Rev. 0 Page 81
F
IGURE A-26. PNEUMATIC CONDITIONING UNIT SCHEMATIC AND PARTS LIST (P/N 101920)
ASSEMBLED VIEW
SCALE 1 : 8
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
WASHER #10 FLTW BLACK OXIDE1131581
SCREW 10-24 X 3/4 SHCS1264842
SCREW 10-32 X 1/4 SHCS1472613
(NOT SHOWN) FTG REDUCING ADAPTER 1 NPTF X 1/2 NPTM
1528524
VALVE PUSHBUTTON 5 PORT PNEUMATIC
467852
5
LEGEND PLATE START 10250 SERIES
4679716
PUSHBUTTON GREEN FLUSH
594581
7
PUSH BUTTON PUSH PULL MAINTAINED (M-M)
5945918
PUSH BUTTON OPERATOR RED 1-5/8
5946219
LEGEND PLATE STOP 10250SERIES YELLOW BACKGROUND
59825110
FTG ELBOW 1/8 NPTM X 5/32 TUBE PRESTOLOK
83517111
FTG, STRAIGHT, 1/8 NPTM X 5/32 TUBE PRESTOLOK
83520212
NUT 10-24 STDNYLOC SS
87533413
PLATE PART NO YEAR MODEL 1.5 X 3.0 ADHESIVE BACKED
91792114
BUMPER RUBBER 1/4" ID X 1/2" OD 1/16" MATL THICKNESS
96348415
O-RING 4.5MM ID X 6.5MM OD X 1MM W NITRILE 70A DUROMETER
98553116
(NOT SHOWN) TUBING 5/32 OD POLYURETHANE (INCHES)985542417
FTG STRAIGHT SOCKET HEAD 5/32 TUBE PUSH LOCK 10/32UNF98555
5
18
STAND PCU101003119
FILTER REGULATOR LUBRICATOR CONTROL VALVE W SEMI AUTO DRAIN101206120
(NOT SHOWN) FTG COUPLER 1/2 NPTM X CHICAGO W/ SAFETY PIN & LANYARD2151012221
2
4
2
4
STOP
53
1
START
MFG PN
8652A3M04011100
1
3
5
SHUT OFF
MFG PN
8652APAM4FA00GA
MFG PN
8652AL0M40A0000
MFG PN
8652A5E04NA0000
4.0"
6.0"
6.0"
6.0"
