Climax KM3000 - Igure A-18. Gearbox Spindle Drivetop Assembly (P;N 34403)

P/N 104075, Rev. 0 Page 73
F
IGURE A-18. GEARBOX SPINDLE DRIVETOP ASSEMBLY (P/N 34403)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
SCREW 8-32 X 5/8 SHCS
1015661
SCREW 10-32 X 5/8 SHCS
1015762
SEAL 1.000 ID X 1.375 OD X .250
1016713
GEAR SPUR 16DP 56T 20PA .43 X .97LG STEEL
1551714
GEARBOX 4TH GENERATION KM3000
342841
5
GEARBOX COVER KM3000
3428516
LABEL WARNING - CUTTING OF FINGERS OR HAND ROTATING BLADE GRAPHIC
1.13 TALL TRIANGLE YELLOW
7984817
5
2
4
7
6
1
3
