Page 10 KM3000 KM4000 Operating Manual
2.2 CONTROLS
FIGURE 2-2. KM3000 MOTOR
The KM3000/KM4000 key mill machine is available in electric, pneumatic and
hydraulic versions.
2.2.1 KM3000/KM4000 electric power
Table 2-2 lists operating specifications of the electrically powered version of the
KM3000/KM4000.
Prolonged operation of the motor above the design current will result in
excessive heat generation and motor damage. Motor failure can occur
suddenly and without warning above the maximum current.
TABLE 2-2. ELECTRIC POWER SPECIFICATIONS
Voltage type: 110-130 VAC 50/60Hz 220-240 VAC 40/60Hz
Design current: 13A 6.6A
Maximum current: 15A 7.0A
Duty cycle: 75% (45 min per hour) 75% (45 min per hour)
