Climax KM3000 - Igure A-14. Top Slide Assembly (P;N 75077)

P/N 104075, Rev. 0 Page 69
F
IGURE A-14. TOP SLIDE ASSEMBLY (P/N 75077)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
SCREW 5/16-18 X 1-1/4 SHCS
1173511
SLIDE TOP INCH 2ND KM3000
SLIDE TOP METRIC 2ND KM3000
15507
16026
12
SHAFT ASSY TRAVERSE DRIVE 2ND KM30001565713
3
1
2
AVAILABLE CONFIGURATIONS
PART NO DESCRIPTION
15656
ASSY TOP SLIDE INCH 2ND KM3000
16025
ASSY TOP SLIDE METRIC 2ND KM3000
