Page 76 KM3000 KM4000 Operating Manual
FIGURE A-21. SPINDLE AND QUILL ASSEMBLY (P/N 15651)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
BRG BALL .7874 ID X 1.8504 OD X .55121015011
ASSY QUILL 2ND KM3000 1.75 TRAVEL1551412
SPINDLE INCH 5/8 3RD KM30001551813
SEAL 1.500 ID X 1.874 OD X .2501566914
SCREW 1/2-20 X .425 END MILL SET SCREW
374051
5
5
3
4
2
1
