Climax KM3000 - Igure A-12. Base and Top Slide Assembly Metric (P;N 30459)

P/N 104075, Rev. 0 Page 67
F
IGURE A-12. BASE AND TOP SLIDE ASSEMBLY METRIC (P/N 30459)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
SCREW 1/4-20 X 5/8 SSSHDPPL1018961
CRANK HANDLE 1/2 SQUARE1020312
SCREW DRIVE #2 x 1/4 HOLE SIZE .089
1058843
BASE 2ND KM3000
1550514
GIB .4915 X .1562 X 6.76 0-1 6 SS X 1.25
156161
5
CLAMP ASSY STANDARD KM3000
1564716
ASSY TOP SLIDE METRIC 2ND KM3000
160251
7
MANUAL INSTRUCTION KM3000 KEY MILL 4TH GEN (NOT SHOWN)
1632518
PLATE MASS CE
2915219
ASSY LEADSCREW TOP SLIDE KM3000
38091110
4
9
3
2
7
1
5
10
10
6
