Page 12 KM3000 KM4000 Operating Manual
2.2.2 KM3000/KM4000 pneumatic power
Figure B-1 on page 79 shows the pneumatic schematic.
CAUTION
The motor must be operated with sufficient load to prevent speed from
exceeding maximum allowable speed.
Emergency shutdown
To stop machine operation immediately, press the emergency stop button on the
PCU.
Before restarting a pneumatic-powered KM3000/KM4000, do the following:
1. Check that the area around the machine swing area is free from loose tools,
obstructions or personnel.
2. Close the speed adjustment valve.
3. Pull the emergency stop button up.
4. Press the start button (repeat step 1 if necessary).
The KM3000/KM4000 controls are located on the PCU, shown in Figure 2-4 on
page 13.
TABLE 2-4. SPINDLE SPEED SPECIFICATIONS
Motor Setting Spindle Speed
Setting 1 180 RPM
Setting 2 260 RPM
Setting 3 320 RPM
Setting 4 390 RPM
Setting 5 460 RPM
Setting 6 530 RPM
TABLE 2-5. PNEUMATIC SPECIFICATIONS
Maximum working pressure: 90 psi (6.2 Bar)
Working temperature range: 27–150°F (-3–65°C)
Flow rate: 48 SCFM (1.36 m
3
/min)
Maximum allowable motor speed: 1,100 RPM
