P/N 104075, Rev. 0 Page 97
15654 BRG NEEDLE 1-1/2 ID X 1-7/8 OD X .625 OPEN 1
15666 WASHER THRUST .669 ID X 1.181 OD X .039 1
15667 WASHER SPRING FINGER .688 ID X 1.164 OD (KB) 1
15668 RING SNAP .672 OD X .035 THICK INVERTED 1
15999 PLUG HOLE 1-3/4 DIA MODIFIED (KB) 1
19016 BRG NEEDLE 1-1/2 ID X 1-7/8 OD X .625 OPEN GR 1
19634 LEADSCREW VERT ADJ METRIC 3RD KM4000 CPM 4.67 INCH 1
104074 MANUAL INSTRUCTION KM3000 KM4000 KEY MILL 1
37405 SCREW MODIFIED 1/2-20 X .425 END MILL SCREW 1
37981 NUT SELF LOCKING BRG ADJ SZ 4 1
38116 COLLAR LEADSCREW BEARING (KB) 1
38117 LEADSCREW TOP SLIDE KM4000 PM2000 PM3000 (KB) 1
38120 GEAR BEVEL 16DP 24T 1-1/2:1 20PA STEEL 1
57541 SCREW M5 X 0.8 X 40MM SHCS 4
TABLE A-2. KM4000 230V INCH SPARE PARTS KIT (P/N 103964)
Part number Description Quantity
TABLE A-3. 120V INCH SPARE PARTS KIT (P/N 75012)
Part number Description Quantity
10189 SCREW 1/4-20 X 5/8 SSSHDPPL 6
10190 LEADNUT BRASS (KB) 1
10191 SCREW 3/8-16 X 1 SHCS 1
10193 RING SNAP 1-3/4 ID BEVELED .062 TH 1
10197 NUT 3/4-10 STDN ZINC PLATED 1
10199 WRENCH HEX 1/4" SHORT ARM 1
10200 WRENCH HEX 1/8" SHORT ARM 1
10203 CRANK HANDLE 1/2 SQUARE (KB) 1
10206 ROCKER CHAIN CLAMP (KB) 1
10386 SET END MILL INCH 1/16 INCH INCREMENTS 1
11735 SCREW 5/16-18 X 1-1/4 SHCS 1
12549 SP ARMATURE 3RD 120V 1
12553 SP SCREW BRUSH RETAINING 3RD 2
12554 SP (PLM) BRUSH CARBON 120V 3RD (NOT A PAIR) 4
To Next Page
