Page 96 KM3000 KM4000 Operating Manual
10302 COLLET 16mm (.630) OD X 12mm (.472) ID 1
103346 GEAR SPUR 16DP 16T 20PA .38LG STEEL 2
10365 BRG BALL .6693 ID X 1.5748 OD X .4724 2 SEALS 2
103705 GEAR SPUR 16DP 16T 20PA .43 X .73LG M14 STEEL 1
103781 WASHER THRUST 3/8 ID X 3/4 OD X 1/16 OILITE 4
103792 SEAL .8125 ID X 1.250 OD X .188 1
103863 SP BRUSH CARBON PE 15-20 RT MOTOR 230V 1
10387 SET END MILL METRIC 8 10 12 16 18 1
103886 SCREW 5/8-11 X 1 SSSCN 1
104108 SP BRG BALL 6 X 19 X 6 METABO 1
104109 SP BRG BALL 8 X 22 X 7 METABO 1
104111 SP POTI SWITCH METABO 1
104112 SP FAN METABO 1
104113 SP TACHO DISC METABO 1
104114 SP GREASE METABO 1
104115 SP ARMATURE 230V 1
104116 SP FIELD COIL 230V 1
104119 SP CABLE WITH PLUG 230V 1
104120 SP ELECTRONIC UNIT WITH SWITCH 230V 1
104121 SP SPINDLE 230V 1
10431 SCREW 5/16-18 X 1 SHCS 3
10453 SCREW 3/8-16 X 1-1/4 SHCS 1
10588 SCREW DRIVE #2 X 1/4 FOR .089 X .250 DP HOLE 4
11037 BRG NEEDLE 3/8 ID X 9/16 OD X .375 OPEN 2
11735 SCREW 5/16-18 X 1-1/4 SHCS 1
11736 WASHER THRUST .500 ID X .937 OD X .030 1
11845 SCREW 8-32 X 1/2 SHCS 7
11849 BRG BALL .6693 ID X 1.3780 OD X .3937 2 SEALS 1
13174 BRG THRUST .875 ID X 1.437 OD X .0781 2
13175 WASHER THRUST .875 ID X 1.437 OD X .060 4
13542 BRG ANGULAR CONTACT .787 ID X 1.850 OD X .551 2
15618 SHAFT ASSY 2ND KM3000 (KB) 1
TABLE A-2. KM4000 230V INCH SPARE PARTS KIT (P/N 103964)
Part number Description Quantity
To Next Page
