Climax KM3000 - Igure A-32. Hydraulic Motor Assembly (P;N 81521)

P/N 104075, Rev. 0 Page 87
F
IGURE A-32. HYDRAULIC MOTOR ASSEMBLY (P/N 81521)
PARTS LIST
DESCRIPTION
PART No.
QTY
ITEM
SCREW 1/4-20 X 3/4 SHCS
1016021
SCREW 1/4-28 X .75 SHCS
1264712
FTG ELBOW SAE-6 MALE X #6 JIC MALE 90 DEG
1284923
SCREW 1/4-28 X 5/8 FHSCS128533
4
GEAR SPUR MOTOR 16DP 1.625PD SPECIAL HYD MOTOR
2037915
MOTOR HYD. .79 CU IN. 5/8 STRAIGHT SAE -6F SIDE PORTS MOTOR HYD 1.93 CU IN. 5/8 STRAIGHT SAE O-RINGS SIDE PORTS MOTOR HYD 1.21 CU IN. CHAR-LYNN
14261 20371 21025
16
FLANGE MOTOR MTG HYD 4TH GEN GEARBOX
350031
7
LABEL WARNING CRUSH FOOT7874118 LABEL WARNING FLYING DEBRIS/LOUD NOISE78748 19 LABEL WARNING - CUTTING OF FINGERS OR HAND ROTATING BLADE GRAPHIC 1.13 TALL TRIANGLE YELLOW
79848110
ASSY HOSE 3/8 X 1/2 QD MALE X #6 JICF X 24 CE
80041211
3
10
9
8
6
7
4
1
5
2
GEAR BOX REF. ONLY
11
AVAILABLE CONFIGURATIONS
P/N DESCRIPTION
21023
MOTOR HYD ASSY 1.21 CU IN. CHAR-LYNN KM3000 KM4000 CPM (SHOWN)
21027 MOTOR HYD ASSY 1.93 CU IN. CHAR-LYNN KM300 KM4000 CPM 21029
MOTOR HYD ASSY .79 CU IN. CHAR-LYNN KM3000 KM4000 CPM
