Page 58 KM3000 KM4000 Operating Manual
FIGURE A-3. KM3000/KM4000 PNEUMATIC ASSEMBLY (P/N 85123)
8
6
8
5
3
4
AVAILABLE CONFIGURATIONS
PART NO. DESCRIPTION
16002
MODEL KM3000 INCH AIR
16005
MODEL KM3000 METRIC AIR
