FIGURE A-15. TOP SLIDE LEADSCREW ASSEMBLY (P/N 38091)
PARTS LIST
DESCRIPTION
PART No.
QTY
ITEM
LEADNUT BRASS 3/4-10 ACME
1019011
SCREW 3/8-16 X 1 SHCS
1019112
RING SNAP 1.75 ID BEVEL LEADSCREW1019313
BRG THRUST .875 ID X 1.437 OD X .0781
1317424
WASHER THRUST .875 ID X 1.437 OD X .060
131754
5
PLUG HOLE 1-3/4 DIA MODIFIED1599916
NUT SELF LOCKING BRG ADJ SZ 4
379811
7
LEADSCREW TOPSLIDE KM3000
3809218
COLLAR LEADSCREW BEARING
3811619
8
4
4
9
7
3
1
2
5
5
6
