Climax KM3000 - Igure A-20. Vertical Leadscrew Assembly (P;N 75096)

P/N 104075, Rev. 0 Page 75
F
IGURE A-20. VERTICAL LEADSCREW ASSEMBLY (P/N 75096)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
COLLAR
1016511
PIN ROLL 1/8 DIA X 1
1016612
DIAL INCH
DIAL METRIC
10169
10170
13
BRG BALL .6693 ID X 1.5748 OD X .4724 2 SEALS
1036524
WASHER THRUST .669 ID X 1.181 OD X .039
1566615
WASHER SPRING FINGER .688 ID X 1.164 OD
1566716
RING SNAP .672 OD X .035 THICK INVERTED156681
7
LEADSCREW VERT ADJ INCH 3RD KM4000 CPM 4.67 INCH (19648)
LEADSCREW VERT ADJ INCH 3RD KM3000 2.50 INCH (15655)
LEADSCREW VERT ADJ METRIC 3RD KM3000 2.50 INCH (16021)
LEADSCREW VERT ADJ METRIC 3RD KM4000 CPM 4.67 INCH (19649)
19492
15635
16020
19634
18
4
4
1
2
3
6
5
7
8
AVAILABLE CONFIGURATIONS
P/N DESCRIPTION
15655
ASSY LEADSCREW VERT ADJ INCH 3RD KM3000
16021
ASSY LEADSCREW VERT ADJ METRIC 3RD KM3000
19648
ASSY LEADSCREW VERT ADJ INCH 3RD KM4000 CPM
19649
ASSY LEADSCREW VERT ADJ METRIC 3RD KM4000 CPM
