Climax KM3000 - Able A-4. 230 V Metric Spare Parts Kit (P;N 68419)

Page 98 KM3000 KM4000 Operating Manual
13174 BRG THRUST .875 ID X 1.437 OD X .0781 2
13175 WASHER THRUST .875 ID X 1.437 OD X .060 4
15635 LEADSCREW VERT ADJ INCH 3RD KM3000 2.50 INCH (KB) 1
15647 CLAMP ASSY STANDARD KM3000 1
15657 SHAFT ASSY TRAVERSE DRIVE 2ND KM3000 1
104074 MANUAL INSTRUCTION KM3000 KM4000 KEY MILL 1
27366 CHAIN WRENCH 3/4 PITCH .240 DIA PIN 32
27385 BOLT CHAIN CLAMP 3/4 PITCH WRENCH CHAIN (KB) 1
34653 GEAR SPUR 16DP 26T 20PA .437 X .78LG STEEL 1
37405 SCREW MODIFIED 1/2-20 X .425 END MILL SCREW 1
37981 NUT SELF LOCKING BRG ADJ SZ 4 1
38091 ASSY LEADSCREW TOP SLIDE KM3000 1
38116 COLLAR LEADSCREW BEARING (KB) 1
TABLE A-3. 120V INCH SPARE PARTS KIT (P/N 75012)
Part number Description Quantity
TABLE A-4. 230V METRIC SPARE PARTS KIT (P/N 68419)
Part number Description Quantity
10189 SCREW 1/4-20 X 5/8 SSSHDPPL 6
10190 LEADNUT BRASS (KB) 1
10191 SCREW 3/8-16 X 1 SHCS 1
10193 RING SNAP 1-3/4 ID BEVELED .062 TH 1
10197 NUT 3/4-10 STDN ZINC PLATED 1
10199 WRENCH HEX 1/4" SHORT ARM 1
10200 WRENCH HEX 1/8" SHORT ARM 1
10203 CRANK HANDLE 1/2 SQUARE (KB) 1
10206 ROCKER CHAIN CLAMP (KB) 1
10302 COLLET 16mm (.630) OD X 12mm (.472) ID 1
10387 SET END MILL METRIC 8 10 12 16 18 1
11735 SCREW 5/16-18 X 1-1/4 SHCS 1
12553 SP SCREW BRUSH RETAINING 3RD 2
13174 BRG THRUST .875 ID X 1.437 OD X .0781 2
