Climax KM3000 - Igure A-34. Km4000 Chain Clamp Assembly (P;N 10491)

P/N 104075, Rev. 0 Page 89
F
IGURE A-34. KM4000 CHAIN CLAMP ASSEMBLY (P/N 10491)
PARTS LIST
DESCRIPTIONP/N:QTY
ITEM
ROCKER CHAIN CLAMP
1020641
NUT 3/4-10 STDN ZINC PLATED
1019742
WASHER THRUST .750 ID X 1.250 OD X .123
1019843
CLAMP BAR
1046224
CASTING BLOCK CLAMP SMALL
1550445
SCREW 1/2-13 X 1 LHSCS15670
4
6
BOLT - CHAIN CLAMP 3/4 PITCH CHAIN27385
47
CHAIN WRENCH 3/4 PITCH .240 DIA PIN (VMI)2736680 IN8
NOTES
1 BREAK CHAIN INTO 20 INCH LENGTHS (QTY 4)
6
5
8
7
4
1
3
2
PN 13262
