P/N 104075, Rev. 0 Page 99
13175 WASHER THRUST .875 ID X 1.437 OD X .060 4
15647 CLAMP ASSY STANDARD KM3000 1
15657 SHAFT ASSY TRAVERSE DRIVE 2ND KM3000 1
16020 LEADSCREW VERT ADJ METRIC 3RD KM3000 2.50 INCH (KB) 1
104074 MANUAL INSTRUCTION KM3000 KM4000 KEY MILL 1
27366 CHAIN WRENCH 3/4 PITCH .240 DIA PIN 32
27385 BOLT CHAIN CLAMP 3/4 PITCH WRENCH CHAIN (KB) 1
31437 SP FIELD 230 VOLT MILWAUKEE 5535 AND 5455 1
31769 SP (PLM) BRUSH CARBON KM3000/87 MOTOR 230V 4
34653 GEAR SPUR 16DP 26T 20PA .437 X .78LG STEEL 1
37405 SCREW MODIFIED 1/2-20 X .425 END MILL SCREW 1
37981 NUT SELF LOCKING BRG ADJ SZ 4 1
38091 ASSY LEADSCREW TOP SLIDE KM3000 1
38116 COLLAR LEADSCREW BEARING (KB) 1
39304 SP ARMATURE 230V REWIND 1
TABLE A-4. 230V METRIC SPARE PARTS KIT (P/N 68419)
Part number Description Quantity
TABLE A-5. PNEUMATIC INCH SPARE PARTS KIT (P/N 103866)
Part number Description Quantity
10167 SEAL 1.000 ID X 1.375 OD X .250 1
10189 SCREW 1/4-20 X 5/8 SSSHDPPL 6
10190 LEADNUT BRASS (KB) 1
10191 SCREW 3/8-16 X 1 SHCS 1
10193 RING SNAP 1-3/4 ID BEVELED .062 TH 1
10197 NUT 3/4-10 STDN ZINC PLATED 1
10199 WRENCH HEX 1/4" SHORT ARM 1
10200 WRENCH HEX 1/8" SHORT ARM 1
10203 CRANK HANDLE 1/2 SQUARE (KB) 1
10206 ROCKER CHAIN CLAMP (KB) 1
10326 GEAR SPUR 26T 16DP 1.625PD 1
10386 SET END MILL INCH 1/16 INCH INCREMENTS 1
11735 SCREW 5/16-18 X 1-1/4 SHCS 1
To Next Page
