Page 30 KM3000 KM4000 Operating Manual
CAUTION
The key mill has a maximum vertical adjustment height of 1.75" (44
mm) from the bottommost position. Cranking the key mill above this
height will cause the vertical adjustment leadscrew to unthread from the
base.
FIGURE 3-7. VERTICAL AND HORIZONTAL FEED CONFIGURATION
