page 97 of 120
User button function Description
System unit changes the scale units between imperial
or metric
Steath mode all turns the illumination of all LBUS devices
on the camera side o or on
Laser pointer turns the laser pointer on as long as the
button is being pressed
Camera rec starts and stops the camera
Lock knob digitally locks and unlocks the knob
*Lock slider digitally locks and unlocks the slider
*Lock joystick digitally locks and unlocks the joystick
Lock thumb wheel digitally locks and unlocks the thumb wheel
**Filter increase increases the cmotion Cinefade VariND
lter by ND0.1 in VariND mode and 5° in
RotaPola mode
**Filter decrease decreases the cmotion Cinefade VariND
lter by ND0.1 in VariND mode and 5° in
RotaPola mode
**Cinefade set sets the Cinefade start exposure
Load lens opens the load lens menu
Load pre-marked ring opens the load pre-marked ring menu
Load pre-marked strip opens the load pre-marked strip menu
Camera button 1-6 triggers the assigned camera feature on
the camera
Marker focus a single press sets a focus marker on the
focus scale. When highlighted in yellow, a
single press allows you to change the color
(R,G,B). You can set up to three color-cod-
ed digital focus marks. Pressing the user
button for 3 seconds will delete the select-
ed marker. Pressing the user button for 6
seconds will delete all markers from the
scale. A set focus marker will give progres-
sive haptic feedback when getting close to
and hitting your mark.
Marker iris a single press sets an iris marker on the
iris scale. When highlighted in yellow, a sin-
gle press allows you to change the color
(R,G,B). You can set up to three color-cod-
ed digital iris marks. Pressing the user but-
ton for 3 seconds will delete the selected
marker. Pressing the user button for 6 sec-
onds will delete all markers from the scale.
A set iris marker will give progressive hap-
tic feedback when getting close to and hit-
ting your mark.
