Item Description
Enable Port Forwarding Please select to enable Port Forwarding service or not.
IP Address Please specify the IP address which receives the incoming packets.
Protocol Please select the protocol type.
Port Range Please enter the port number, for example 80-80 or 20-22
Comment You can add comments for this port forwarding rule.
Apply Change & Reset
Click on Apply Changes to save the setting data. Or you may click on
Reset to clear all the input data.
Cur
Table
It will display all port forwarding regulation you made.
Delete Selected & Delete All
Click Delete Selected will delete the selected item. Click Delete All
will delete all items in this table.
Reset
You can click Reset to cancel.
*The following figure shows the IP forwarding configuration of your web on a local area network. The
web server is located on 192.168.1.100, forwarding port is 80, and type is TCP+UDP.
Configuration:
Private IP: 192.168.1.100
Port: 80 - 80
Type: TCP+UDP
