Chapter 4. Configuration and Operation
141
If single channel bank or dual channel bank is selected, the system queries as to whether timing should
be loop or local shelf timing (Figure 4-48).
Shelf Timing
L) Loop
C) Local
[ ]
Figure 4-48. Selecting Shelf Timing
When Loop timing is selected for dual channel bank mode, the system prompts with the following
choices as shown in Figure 4-49.
Network Clock Connected to
1) T1-1
2) T1-2
3) T1-1 and T1-2
[ ]
Figure 4-49. Selecting Network Clock with Loop Timing for Dual Channel Bank Operation
For all modes except ALPS, the system displays the screens below (Figures
4-50 and 4-51), in order to specify a frame mode, and zero suppression mode, compatible with the
network.
Frame Mode
S) D4/SF
E) ESF
[ ]
Figure 4-50. Specifying Frame Mode
