Chapter 3. Installation
69
Table 3-10. 50-Pin Connector Pin-Outs
for the 24-Slot Shelf
Card Slot Channel A Channel B
R & T R1 & T1 M & E R & T R1 & T1 M & E
1 P4 - 1/26 P5 - 1/26 P6 - 1/26 P4 - 13/38 P5 - 13/38 P6 - 13/38
2 P4 - 2/27 P5 - 2/27 P6 - 2/27 P4 - 14/39 P5 - 14/39 P6 - 14/39
3 P4 - 3/28 P5 - 3/28 P6 - 3/28 P4 - 15/40 P5 - 15/40 P6 - 15/40
4 P4 - 4/29 P5 - 4/29 P6 - 4/29 P4 - 16/41 P5 - 16/41 P6 - 16/41
5 P4 - 5/30 P5 - 5/30 P6 - 5/30 P4 - 17/42 P5 - 17/42 P6 - 17/42
6 P4 - 6/31 P5 - 6/31 P6 - 6/31 P4 - 18/43 P5 - 18/43 P6 - 18/43
7 P4 - 7/32 P5 - 7/32 P6 - 7/32 P4 - 19/44 P5 - 19/44 P6 - 19/44
8 P4 - 8/33 P5 - 8/33 P6 - 8/33 P4 - 20/45 P5 - 20/45 P6 - 20/45
9 P4 - 9/34 P5 - 9/34 P6 - 9/34 P4 - 21/46 P5 - 21/46 P6 - 21/46
10 P4 - 10/35 P5 - 10/35 P6 - 10/35 P4 - 22/47 P5 - 22/47 P6 - 22/47
11 P4 - 11/36 P5 - 11/36 P6 - 11/36 P4 - 23/48 P5 - 23/48 P6 - 23/48
12 P4 - 12/37 P5 - 12/37 P6 - 12/37 P4 - 24/49 P5 - 24/49 P6 - 24/49
13 P1 - 1/26 P2 - 1/26 P3 - 1/26 P1 - 13/38 P2 - 13/38 P3 - 13/38
14 P1 - 2/27 P2 - 2/27 P3 - 2/27 P1 - 14/39 P2 - 14/39 P3 - 14/39
15 P1 - 3/28 P2 - 3/28 P3 - 3/28 P1 - 15/40 P2 - 15/40 P3 - 15/40
16 P1 - 4/29 P2 - 4/29 P3 - 4/29 P1 - 16/41 P2 - 16/41 P3 - 16/41
17 P1 - 5/30 P2 - 5/30 P3 - 5/30 P1 - 17/42 P2 - 17/42 P3 - 17/42
18 P1 - 6/31 P2 - 6/31 P3 - 6/31 P1 - 18/43 P2 - 18/43 P3 - 18/43
19 P1 - 7/32 P2 - 7/32 P3 - 7/32 P1 - 19/44 P2 - 19/44 P3 - 19/44
20 P1 - 8/33 P2 - 8/33 P3 - 8/33 P1 - 20/45 P2 - 20/45 P3 - 20/45
21 P1 - 9/34 P2 - 9/34 P3 - 9/34 P1 - 21/46 P2 - 21/46 P3 - 21/46
22 P1 - 10/35 P2 - 10/35 P3 - 10/35 P1 - 22/47 P2 - 22/47 P3 - 22/47
23 P1 - 11/36 P2 - 11/36 P3 - 11/36 P1 - 23/48 P2 - 23/48 P3 - 23/48
24 P1 - 12/37 P2 - 12/37 P3 - 12/37 P1 - 24/49 P2 - 24/49 P3 - 24/49
