Coatmaster Flex User Manual

coatmaster Flex
23
8. Operating Instructions
The following steps guide you step-by-step through the individual processes and menus. For the navigation
in the following sections, the arrow keys and buttons of the input panel are used according to section 7.2.
(Figure 8: Input panel - keys and elements).
8.1. System Settings
In the main menu, select the system settings icon in the top right corner by using the left or right arrow
key   Ⓓand the OK button Ⓒ to select and open the system settings menu.
Figure 16: System settings menu
System settings contain the following categories:
•
Network
To select and connect to a local Wi-Fi network
(see section 7.5.).
•
Network Troubleshooter
(Sub menu of Network) To perform a network
diagnosis and obtain information on the Wi-Fi status (see
section 8.1.1.).
•
Language
To change the language (see section 7.4.).
•
User Level
To differentiate between the operational functionalities
in the Standard or Advanced modes (see section 8.1.3.).
•
Measurement Unit
To configure and display measurement results
in micrometres (µm) or in mils (see section 8.1.4.).
•
Auto power off
To change the time setting when the Flex should
turn off automatically (see section 8.1.5.).
•
Contact
To display the contact information as well as
the software version of the UI and the system.
•
Automation mode
To start and stop the automation mode
(see section 8.1.8.).
•
Factory Reset
To return the system to the factory settings
(see section 8.1.7.).
Choose the desired menu in the list, using the up/down arrow
keys and the OK button Ⓒ to validate.
