Troubleshooting
The following figure shows the media path, and indicates the lower
and upper parts of the imager.
Cross-Section of Imager, Showing Internal Media Path
Clearing a jam from these likely locations is described in the
following topics.
Receive
trays
Diverter
Ribbon
carriage
Pinch
Capstan
Platen Roller
Hide track
Print head
Cassettes
Cassette doors
Basement
Pickers
Pick tires
Media guides
Upper Part
Lower Part
To Next Page
