3-8 Media Handling and Storage
4. Remove the old ribbon, as shown in the following figure.
5. Load the new ribbon, as shown in the following figure.
Spring-loaded
spindles
Spring-loaded
spindles
Black (Supply)
Gray (Take-up)
