4. To refit the Hold Up Roller
Unit Support Bar, position the
left end under the Drive shaft
at the lift end of the recess.
NOTE: It may be easier to fit with the Hold Up
Roller Unit Collar Assembly removed, but
remember to return it before refitting the Hold
Up Roller Unit.
5. Lower the Hold Up Roller
Unit Support Bar into the
recess and make sure it sits
level.
6. Refit the Hold Up Roller Unit
as described in chapter “14.6
Hold Up Roller Unit” page 75.
