InteliMains
NT
, SW version 3.0
InteliMains-NT-BTB-3.0-Reference Guide.pdf, ©ComAp – June 2013
CAUTION!
Make sure all controllers have this setpoint set to AUT. It does
not work properly if there are controllers with this setpoint
adjusted to OFF and others with AUT setting.
CAUTION!
This function is not designed to cooperate with controllers which
do not support it. Make sure it is adjusted to OFF if there are
other controllers on the CAN without this setpoint.
12.2.3.18 Setpoint: IP Addr mode
The setpoint is used to select the method how the ethernet connection is
adjusted.
The ethernet connection is adjusted fixedly according to
the setpoints IP address, Net mask, Gateway IP, DNS
IP. .
This method should be used for classic ethernet or
Internet connection. When this type of connection is
opening the controller is specified by it's IP address.
That means it would be inconvenient if the IP address
were not fixed (static).
The ethernet connection settings is obtained
automatically from the DHCP server. The obtained
settings is then copied to the related setpoints (it is not
possible to set those setpoints manually in this setting,
for more information please see the following setpoints:
IP address, Net mask, Gateway IP and DNS IP). If the
process of obtaining the settings from DHCP server is
not successful the value 000.000.000.000 is copied to
the setpoint IP address and the module continues trying
to obtain the settings.
This method is beneficial for AirGate connection as it
makes the connection very easy, in fact "plug and play".
When this type of connection is opening the controller is
specified by it's AirGate ID and the IP address does not
play any role.
